Description
Dimensions Table
| EdgeVend Article Number |
Manufacturer Part Number |
Thread Size A1 |
Thread Tolernance |
Thread Form |
Thread Norm DIN |
Cutting Length B2(mm) |
Usable Length B4(mm) |
Overall Length B5(mm) |
Shank Diameter C3(mm) |
Wrench Size □(mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| EV-TA-0000803 | 9128181 | M10x1-6HX | 6HX | C | DIN 374 | 18.0 | — | 90.0 | 7.0 | — |
| EV-TA-0000805 | 9128183 | M12x1,5-6HX | 6HX | C | DIN 374 | 20.0 | — | 100.0 | 9.0 | — |
| EV-TA-0000807 | 9128185 | M16x1,5-6HX | 6HX | C | DIN 374 | 20.0 | — | 100.0 | 12.0 | — |
| EV-TA-0000808 | 9128186 | M18x1,5-6HX | 6HX | C | DIN 374 | 22.0 | — | 110.0 | 14.0 | — |
| Please choose options to see the values. | ||||||||||
Get your right Pre-Drill
| Drill EdgeVend Article Number |
Drill Manufacturer Part Number |
Drill Diameter Ø(mm) |
Drill L×D |
Depth of Cut(mm) |
ISO Suitability | Price | Quantity | Direct add to Cart |
|
|---|---|---|---|---|---|---|---|---|---|
| Select a variant to see compatible pre-drills. | |||||||||
Cutting Data
| ISO | Material | Operation | Ø Pre-Drill(mm) | Coolant | vc min(m/min) | vc typ(m/min) | vc max(m/min) |
|---|---|---|---|---|---|---|---|
| Start here: Please choose a variant. | |||||||
