Beskrivelse
Produktmål (se produktbilleder for mål)
| EV SKU | Manufacturer Part Number |
A1 | Tolerance | Form | DIN | B2(mm) | B4(mm) | B5(mm) | C3(mm) | □(mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| EV-TA-0000842 | 1401175 | M5x0,8-6HX | 6HX | C | DIN 371 | 15.0 | 25.0 | 70.0 | 6.0 | — |
| EV-TA-0000843 | 1401177 | M6x1-6HX | 6HX | C | DIN 371 | 16.0 | 30.0 | 80.0 | 6.0 | — |
| EV-TA-0000844 | 1401183 | M12x1,75-6HX | 6HX | C | DIN 376 | 24.0 | 50.0 | 110.0 | 9.0 | — |
| EV-TA-0000845 | 1401303 | M8x1-6HX | 6HX | C | DIN 374 | 14.0 | 35.0 | 90.0 | 6.0 | — |
| EV-TA-0000847 | 1401307 | M10x1-6HX | 6HX | C | DIN 374 | 15.0 | 35.0 | 90.0 | 7.0 | — |
| EV-TA-0000848 | 1401315 | M12x1,25-6HX | 6HX | C | DIN 374 | 18.0 | 45.0 | 100.0 | 9.0 | — |
| EV-TA-0000859 | 9128425 | M3x0,5-6HX | 6HX | E | DIN 2174 | 11.0 | 18.0 | 56.0 | 3.5 | — |
| EV-TA-0000860 | 9128441 | M4x0,7-6HX | 6HX | E | DIN 2174 | 13.0 | 21.0 | 63.0 | 4.5 | — |
| EV-TA-0000861 | 9128443 | M5x0,8-6HX | 6HX | E | DIN 2174 | 15.0 | 25.0 | 70.0 | 6.0 | — |
| EV-TA-0000862 | 9128447 | M6x1-6HX | 6HX | E | DIN 2174 | 16.0 | 30.0 | 80.0 | 6.0 | — |
| EV-TA-0000863 | 9128453 | M8x1,25-6HX | 6HX | E | DIN 2174 | 18.0 | 35.0 | 90.0 | 8.0 | — |
| Please choose options to see the values. | ||||||||||
Find det rigtige forboreværktøj
| Drill EV SKU | Manufacturer Part Number |
Ø(mm) | L×D | DOC(mm) | ISO suitability | Price | Qty | Add | |
|---|---|---|---|---|---|---|---|---|---|
| Select a variant to see compatible pre-drills. | |||||||||
Anvendelse (find dine rigtige skæredata)
| ISO | Material | Operation | Ø Pre-Drill(mm) | Coolant | vc min(m/min) | vc typ(m/min) | vc max(m/min) |
|---|---|---|---|---|---|---|---|
| Start here: Please choose a variant. | |||||||
